Features and Benefits

• Premium efficiency - Up to 20 SEER2
• Product designed to use R454B refrigerant
• Optional communication between Bosch BOVA20 and BIVA20 Air Handler unit
• Outdoor coil - copper tube with hydrophilic aluminum fins
• 10 speed ECM outdoor motor for quiet and efficient operation
• Inverter Drive Compressor (35%-138% speed in cooling, 34%-130% speed in heating), modulation in 1% increments
• Whisper Quiet operation
• Small footprint - 29-1/8" (W) x 29-1/8" (D)
• Easy to install - compatible with most standard 24 VAC heat pump thermostats

‍Standard Features

• Intelligent Oil Return Technology
• Inverter Driven Rotary Compressor
• Crankcase Heater Standard
• Compressor Sound Blanket
• Multiple System Protection:
  • High pressure switch and low pressure transducer
  • Compressor liquid return protection
  • Compressor high or low compression ratio protection
  • Compressor high temperature protection
  • High / low voltage protection and over current protection
  • IPM and electronic control board high temperature protection
• Outdoor coil is capable of withstanding 1000 hour salt spray test according to ASTM B117 standard
• AHRI certified; ETL listed

‍
